304/304L/TP304 Stainless Steel Square Pipe

Stainless Steel Square Pipe

The stainless steel square tube is a hollow strip of steel, which is called a square tube because the section is square.

a large number of pipes used to transport fluids, such as oil, natural gas, water, gas, steam, etc.

In addition, when the bending and torsional strength are the same, the weight is lighter.

Therefore, it is also widely used in the manufacture of mechanical parts and engineering structures.

Specification

5*5~150*150 mm

Thickness

0.4~6.0 mm

Material

304、304L、TP304、TP316L、316、316L、316Ti、321、347H、310S.

（What we are talking about in this article is the 300 series stainless steel square tube）

Classification

Stainless steel square tube classification:

Square tube is divided into seamless steel pipe and welded steel pipe (with seam pipe).

According to the shape of the section, it can be divided into square and rectangular tubes.

Widely used are round steel pipes, but there are also some special-shaped steel pipes such as semicircular, hexagonal, equilateral triangle, and octagonal.

For stainless steel square tubes subjected to fluid pressure, hydraulic tests are required to verify the pressure resistance and quality.

No leakage, wetting or expansion is allowed under the specified pressure. Some steel pipes are also subjected to the crimping test, the flaring test, the flattening test, etc. according to the standard or the requirements of the purchaser.

Production Process

Round steel preparation → heating → hot rolling perforation → cutting head → pickling → grinding → lubrication → cold rolling processing → degreasing → solution heat treatment → straightening → pipe cutting → pickling → finished product inspection.

304 Stainless Steel Square Tube Manufactured By JawaySteel

Overview

Standard : API
Standard2 : API 5CT, API 5DP, API 5L
Grade Group : 10#-45#, 10Cr9Mo1VNb, 10MoWVNb, 15NiCuMoNb5, API J55-API P110, Mn-V alloy, Mo, STPG42
Grade : 10#, 20#, 45#, 10Cr9Mo1VNb, 10MoWVNb, 15NiCuMoNb5, API J55, 15MnV, 15Mo3, STPG42
Thickness : 2 – 50 mm
Section Shape : Round
Outer Diameter(Round) : 20 – 400 mm
Place of Origin : DAINAN, China (Mainland)
Secondary Or Not : Non-secondary
Application : Oil Pipe
Technique : Cold Drawn
Certification : CE
Surface Treatment : Stainess
Special Pipe : Thick Wall Pipe
Alloy Or Not : Is Alloy
Finish : Bright Annealing

Supply Ability

1000 Ton/Tons per Month

Packaging & Delivery

According to export standars or customers’ requiremtnts

Lead Time

Shipped in 10 days after payment

Product Description

Product Name	304 stainless square tube
Size	OD	159–3020mm in Theory
	Thickness	4–25mm in Theory
	Length	Usually 6~12 Meters, 20 Meters Max in Theory

Material	Chinese Grade		06Cr19Ni10
	Foreign Grade		ASTM	304
			EN
Usage	Used For Water, Sewage, Gas, Stream, Combustible Fluids(Petroleum and Gas)
Ends	Beveled (Can be Protected By Plastic Caps or Steel Rings According to Your Requirements)Also We Can Weld Flanges on the Pipe Ends Plain Ends
Surface	Bared Or Paint With Oil, Bitumen,1-3 layer PE
Inspection	With Chemical Composition and Mechanical Properties Testing; Hydrostatic Test, Dimensional and Visual Inspection, Also With Nondestructive Inspection
Technique	Hot Rolled and SSAW or DSAW
Package	Package With Steel Strip When O.D≤273MM, Otherwise In Bulk.
Date of Delivery	According to The Specifications And the Quantities, Time Begin When We confirm the Date of the Earnest or L/C
Method of Payment	T/T L/C West Union
Method Of Delivery	Terms According To the <INCOTERMS 2000> for International Trading,
Others	N/A

304L Stainless Steel Square Tube Manufactured By JawaySteel

Overview

Thickness : 1.0 – 6.0 mm
Section Shape : Square
Outer Diameter : stainless steel pipe
Secondary Or Not : Non-secondary
Application : stainless steel pipe
Technique : ERW
Certification : 304L stainless square steel pipe
Surface Treatment : mirror polish
Special Pipe : EMT Pipe
Alloy Or Not : Non-alloy
Material : 304L
Standard : GB,JIS,ASTM,BS
Surface treatment : mirror polish
Shape section : Square
Wall thickness : 1.0mm-6.0mm
Applocation : door and window frame,Mechanical & manufacture etc.
Mini order : 1MT
Delivery time : about 10-15days

Supply Ability

5000 Ton/Tons per Month

Packaging & Delivery

In bulk, bundles come in waterproof cloth

Lead Time :

10 days after received customer’s deposits

Specification(mm) :

22*22*1.0,

24*24*1.0,

25*25*0.7,

40*40*2.0,

40*40*6.0

50*50*1.2,

Application:

staie armrest,door and window frame,Mechanical & manufacture etc.

Payment term:

T/T, L/C

Package:

In smal bundles and come in waterproof cloth, as customer’s demands

Item	304L stainless steel square tube
Standard	ASTM,AISI,JIS,SUS,GB,DIN,EN,etc.
Material	300 series	304L,301,304,304LN,304N, 305,309S,310S,316LN,316,316L, 316N,316Ti,317,317L,329,347,321,etc.
	200 series	201,202.
Specifications	Outside Diameter	4mm-2500mm
	Wall Thickness	1mm-150mm
	Length	1m-12m or as required
Surface	Annealing,polishing,mirror finished,pickling and etc.
Price term	CIF,FOB, CNF,CFR,EX-WORK,etc.
Payment term	T/T,L/C,Western Union.
Export to	Singapore, Canada, Indonesia,Korea, USA, UK, Thailand, Saudi Arabia, Viet Nam, Iran, India, Peru, Ukraine ,Brazil, South Africa, etc.
Package	Export standard package.
Container sizes	20ft GP:5898mm(length) x 2352mm(width) x 2393mm(height)
	40ft GP:12032mm(length) x 2352mm(width) x 2393mm(height)
	40ft HC:12032mm(length) x 2352mm(width) x 2698mm(height)
MOQ	0.5 Ton
Application	Stainless steel tube are widely used in following fields: 1.Petroleum,chemical enterprise,superheater fo boiler, heat exchanger. 2.High temperature resistant transmission fluid pipe in Power station. 3.Ship with pressure pipe. 4.The exhaust purification devices. 5.Construction and ornament. Or we can make it as your requirement.
Contact	If you have any question, please feel free to contact me.

304TP Stainless Steel Square Tube Manufactured By JawaySteel

Overview

Standard : ASTM, DIN, GB, JIS
Standard2 : ANSI A182-2001, DIN 1629/4, DIN 1630, DIN 17175, DIN 2391, DIN 2448, GB 13296-2007, GB/T 14976-2002, JIS G3466
Grade Group : API J55-API P110, Q195-Q345, ST35-ST52, STB35-STB42
Grade : API J55, API K55, API L80, API N80, API P110, Q195, Q235, Q345, ST35, St37, St42-2, St52, STB35, STB42
Thickness : 0.5 – 16 mm
Section Shape : Square
Outer Diameter : 20*20-500*500mm
Place of Origin : DAINAN, China (Mainland)
Secondary Or Not : Non-secondary
Application : Structure Pipe
Technique : ERW
Certification : CE
Surface Treatment : Galvanized
Special Pipe : Thick Wall Pipe
Alloy Or Not : Non-alloy
Product name : Square Steel Tube
Material : Q235
Shape : Square
Usage : Construction,Machinery
Length : 6-12m
Color : Black or as Customers’ Requirement
Surface : Black painted
Packing : Bundles
End protector : Plastic pipe cap

Supply Ability

50000 Ton/Tons per Month

Packaging & Delivery

standard seaworthy packing

Lead Time :

Shipped in 5 days after payment

Product Description

Name	TP304 stainless square tube
Material Grade	Ni 8%, Cr 18%
Tolerance	b) Thickness: +/- 0.02mm
Tolerance	c) Length: +/- 5mm
Test	Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT
Chemical Composition of Material	Material Composition	201	202	304	316	430
	C	≤0.15	≤0.15	≤0.08	≤0.08	≤0.12
	Si	≤1.00	≤1.00	≤1.00	≤1.00	≤1.00
	Mn	5.5-7.5	7.5-10	≤2.00	≤2.00	≤1.00
	P	≤0.06	≤0.06	≤0.045	≤0.045	≤0.040
	S	≤0.03	≤0.03	≤0.030	≤0.030	≤0.030
	Cr	16-18	17-19	18-20	16-18	16-18
	N	3.5-5.5	4-6	8-10.5	10-14
	Mo				2.0-3.0
Mechanical Property	Material Item		201	202	304	316
	Tensile Strength		≥535	≥520	≥520	≥520
	Yield Strength		≥245	≥205	≥205	≥205
	Extension		≥30%	≥30%	≥35%	≥35%
	Hardness (HV)		<253	<253	<200	<200

1) Tube diameter,from 5 to 219mm,pipe wall thickness:0.2 to 3.0mm.

2) Other sizes can be manufactured according to clients’ requirements

3) Material: AISI 201, 202, 304, 316.Our products comply strictly with ISO9001 quality management system in order to ensure the high quality.

4)Finish : 2B (Mill Finish), bright, satin, hairline, mirror

5)Standard : GB,JIS,AISI,AISTM

6)Payment : T/T deposit,balance should be paid before shipment or againest the B/L, L/C at sight

7)Packing :

Inner packing: Each piece by PVC,

Outer packing: Weaving bags, wooden case or steel crate requested by the client.

8) Usage: Our product are widely used for handraill, pillar,windows, door, clothes rack, furniture hardware, dishware, barbecue grill, lighting products, machine parts, bathroom accessories, heating tubes and so on.
