Introduction
316 Stainless Steel Square baris an austenitic chromium nickel steel square bar containing molybdenum which provides superior corrosion resistance and increased strength at elevated temperatures when compared to 304 Stainless.
Widely known as a food grade stainless or marine grade, 316 Stainless is ideally suited for corrosion resistance against a wide range of chemical and acidic corrodents, and marine environment applications. Typical uses of 316 Stainless includes food production, pharmaceutical equipment, furnace parts, heat exchangers, valves and pumps, chemical equipment, and parts for marine use. Primarily offered in a lower carbon, dual grade 316/316L for increased machinability and added corrosion resistance when welded.
316 Stainless is moderate to weld, cut, form and machine with the proper equipment. Metals Depot stocks a wide size assortment of 316 Stainless Steel Square Bars that you can buy online in ready to ship precut or mill lengths or order just what you need custom cut to size in small or large quantity.
Size Range: ½” to 8″ Diameter
Wall Thickness: 0.049″to 0.375 Wall thickness
All Material Produced to ASTM A-554 Specification (Latest Revision)
Chemical composition
| Carbon, Max % |
0.03 |
| Manganese, Max % |
2.00 |
| Phosphorus, Max % |
0.045 |
| Sulphur, Max % |
0.03 |
| Chromium, Max% |
18.0 |
| Nickel, Min% |
14.0 |
| Molybdenum, Max% |
3.0 |
Mechanical behavior
| Tensile Strength ksi |
83 |
| Yield 2% Offset ksi |
38 |
| Elongation in 2” (50.80mm) |
50 |
316 Stainless Steel Square Tube Sizes
| 316 stainless steel square tube – Sizes & Weights | ||||||||
| Gauge | 18 | 16 | 14 | 11 | 7 | 1/4 | 3/8 | |
| Inches | 0.049 | 0.065 | 0.083 | 0.120 | 0.180 | 0.250 | 0.375 | |
| 1/2 | 0.30 | 0.39 | ||||||
| 5/8 | 0.38 | 0.40 | ||||||
| 3/4 | 0.50 | 65.00 | 0.81 | 1.13 | ||||
| 1 | 0.63 | 0.83 | 1.03 | 1.45 | 2.17 | |||
| 1-1/4 | 0.82 | 1.08 | 1.37 | 1.93 | 2.99 | |||
| 1-1/2 | 0.97 | 1.27 | 1.61 | 2.26 | 3.63 | 4.41 | ||
| 1-3/4 | 1.13 | 1.49 | 1.88 | 2.66 | 3.75 | |||
| 2 | 1.30 | 1.69 | 2.14 | 3.06 | 4.46 | 6.01 | ||
| 2-1/2 | 2.72 | 3.88 | 5.68 | 7.67 | ||||
| 3 | 3.29 | 4.97 | 6.90 | 9.35 | ||||
| 3-1/2 | 5.67 | 8.06 | 10.89 | |||||
| 4 | 6.26 | 9.27 | 12.68 | 18.52 | ||||
| 5 | 8.02 | 11.90 | 16.35 | 23.53 | ||||
| 6 | 9.46 | 14.07 | 18.77 | 28.53 | ||||
| 8 | 26.03 | 38.55 | ||||||
| All material produced to ASTM A554 specification (Latest Revision) | ||||||||
316 Stainless Steel Square Tube Supplier Quote
We sorted out the quotations of 306 stainless steel square tubes from 9 suppliers on September 6, 2018 for customers’ reference.
Since the price changes in real time are for reference only, please contact us for the latest 306 stainless steel square tube price.
stainless steel square tubing suppliers cost 316 pipe
AISI 316 Stainless Steel Square Tubing Standard Sizes
ASTM A554 Grade 201 316 304 / Rectangular bar/square tubing / stainlesssteel
High luster elegance 316 stainless steelsquare tubing
40×40 Inox Square Tubing 316 StainlessSteel Square Pipe With Mirror Finished
Top Selling Ss 316 Square 1/4 Inch Stainless Steel Tubing
stainless steel square tubing suppliers cost 316 pipe
AISI Stainless SteelSquare Tubing 316
Square 316 stainless steel tubing
316 Stainless Steel Square Tube supplier
Now Jawaysteel covers a land area of more than 18000 square meters, with 160 employees and 19 technicists. Backed up by our loyalty customers, old and new, as well as our advanced R&D team, Jaway Steel has become a leading stainless steel supplier in china.
Main business
After more than 20 years of development, Jawaysteel is already a first-class supplier of stainless steel products in china, able to provide high quality stainless steel products for customers from all over the world.
Sevice
- All products provide fine packaging
- Strict product testing services
- First-class quality control standards
- Free product samples
Superiority
- Jawaysteel sticks to technical innovation, dealing with everything with rigorous attitube
- Jawaysteel, first-rate production environment, Professional R&D Center and Experimental Center
- Jawaysteel, well-established in domestic market, take part in international competition
- Jawaysteel, building the Top-ranking Brand
Quality Certificates
- Alibaba.com Certified Supplier
- ISO Quality System Standard Certification
- SGS comprehensive inspection agency certification
