The stainless steel coil pipe is generally a disk having a diameter of 0.5 cm to 20 mm and a thickness of 0.1 cm to 2.0 mm;

Widely used in chemical, mechanical, electronic, electric power, textile, rubber, food, medical equipment, aviation, aerospace, communications, petroleum and other industrial fields.

---

Stainless Steel Coil Pipe/Tube Use



Industrial stainless steel coil pipe: heat exchanger, boiler, petroleum, chemical, fertilizer, chemical fiber, pharmaceutical, nuclear power, etc.



Stainless steel coil pipe for fluids: beverages, beer, milk, water systems, medical equipment, etc.



Stainless steel coil pipe for mechanical structures: printing and dyeing, printing, textile machinery, medical equipment, kitchen equipment, automotive and marine accessories, construction and decoration, etc.



Stainless steel bright coil pipe: welded by stainless steel strip and then reduced wall, reducing the thickness from thin to thin, this process can make the wall thickness uniform and smooth, and the wall of the reduced wall is formed without weld.

According to the naked eye, it is a seamless pipe, but the process is determined to be a welded pipe. The process of reducing the wall is accompanied by bright annealing, so that the inner and outer walls do not form an oxide layer, and the inside and outside are bright and beautiful, which is really required for medical products.

The next process requires sizing, that is, large pull small process, determine the outer diameter, the outer diameter tolerance can generally reach plus or minus 0.01mm.



Implementation standards:



ASTM A269-2002 JIS G4305 GB/T 12770-2002GB/T12771-2002

---

Stainless Steel Coil Pipe/Tube Sizes



Material	Specification	Length (m) / root	Withstand voltage (Mpa)
316L、304L、304	1/8″×0.025″	3200	80
316L、304L、304	1/8″×0.035″	3200	100
316L、304L、304	1/4″×0.035″	2000	100
316L、304L、304	1/4″×0.049″	2000	100
316L、304L、304	3/8″×0.035″	1500	80
316L、304L、304	3/8″×0.049″	1500	100
316L、304L、304	1/2″×0.049″	1000	80
316L、304L、304	1/2″×0.065″	1000	100
316L、304L、304	φ3mm×0.7mm	3200	80
316L、304L、304	φ3mm×0.9mm	3200	100
316L、304L、304	φ4mm×0.9mm	3000	100
316L、304L、304	φ4mm×1.1mm	3000	100
316L、304L、304	φ6mm×0.9mm	2000	100
316L、304L、304	φ6mm×1.1mm	2000	100
316L、304L、304	φ8mm×1mm	1800	80
316L、304L、304	φ8mm×1.2mm	1800	100
316L、304L、304	φ10mm×1mm	1500	70
316L、304L、304	φ10mm×1.2mm	1500	70
316L、304L、304	φ10mm×2mm	500	100
316L、304L、304	φ12mm×1.5mm	500	80

Remarks:
Material, specification and length can be customized according to user requirements

---

Stainless Steel Coil Pipe/Tube Supplier Quote

Remarks:

We have collected quotations from Stainless Steel Coil Pipe from 5 suppliers for your reference.

Due to the rapid price changes, it is for reference only. For the latest Stainless Steel Coil Pipe prices, please contact us. (The units in the quotation are divided into kilometers and tons)



ASME stainless steel coil pipe304/316/316L

---

Stainless Steel Coil Pipe/Tube By JawaySteel Products Show
